HDD with Serial Number: WCC0S0758582;
Model: WD10EARX-22N0YB0;
Date: 03 JAN 2012;
DCM: HGRNHT2CAB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CD1/3281;
1 : 1 : CED/3309;
2 : 3 : D25/3365;
ROM F/W version……………………. : 00510022;
Heads map…………………………. : 0,1,3;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;

;

 ;

;

HDD with Serial Number: WMC0T0347945;
Model: WD10EARX-22N0YB0;
Date: 16 FEB 2012;
DCM: HBNNHT2MBB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AE;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C62/3170;
1 : 1 : C4C/3148;
2 : 2 : C1A/3098;

;

ROM F/W version: 00510051;
Preamp vendor: 0x0000;
Preamp revision: 0x0005;

;

HDD with Serial Number: WCC0S0792993;
Model: WD10EARX-22N0YB0;
Date: 06 JAN 2012;
DCM: EHRNHT2CGB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CDA/3290;
1   : 1   : D2F/3375;
2   : 3   : CE9/3305;
ROM F/W version……………………. : 00510045;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;
;
;
;
;

;

HDD with Serial Number: WCC0S0798203;
Model: WD10EARX-22N0YB0;
Date: 05 JAN 2012;
DCM: EGRNHT2CGB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : D66/3430;
1   : 1   : D1B/3355;
2   : 3   : D3C/3388;
ROM F/W version……………………. : 00510022;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;
;
;
;
;

;

HDD with Serial Number: WCC0S0715557;
Model: WD10EARX-22N0YB0;
Date: 03 JAN 2012;
DCM: EARNHT2CAB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C9C/3228;
1 : 1 : D0E/3342;
2 : 3 : CE4/3300;
;
ROM F/W version: 00510022;
Preamp vendor: 0x0000;
Preamp revision: 0x0005;

;

HDD with Serial Number: WMC0S0090545;
Model: WD10EARX-22N0YB0;
Date: 07 JAN 2012;
DCM: DBRCHV2CHB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;
ROM F/W: 00510045;
Heads map: 0,1,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0005;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : DC7/3527;
1   : 1   : D18/3352;
2   : 3   : CBF/3263;
;
;

;

HDD with Serial Number: WMC0S0066129;
Model: WD10EARX-22N0YB0;
Date: 06 JAN 2012;
DCM: DARNHT2CGB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0F/3087;
1 : 1 : C9D/3229;
2 : 3 : C5B/3163;
ROM F/W version……………………. : 00510045;
Heads map…………………………. : 0,1,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

;

HDD with Serial Number: WCC0T0784396;
Model: WD10EARX-22N0YB0;
Date: 06 JAN 2012;
DCM: DANNHT2CGB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AC;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C26/3110;
1   : 1   : C64/3172;
2   : 2   : C0F/3087;
ROM F/W version……………………. : 00510045;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

;

HDD with Serial Number: WCAZAC192414;
Model: WD10EARX-00PASB0;
Date: 19 SEP 2011;
DCM: HHRNNTJMHB;
Product of: Thailand;
PCB Sticker: 2061-771698-904 AB;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C27/3111;
1 : 2 : C1B/3099;
2 : 5 : CA0/3232;
3 : 6 : C30/3120;
4 : 7 : C8D/3213;

;

ROM F/W: 002000A6;
Heads map: 0,2,5,6,7;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

HDD with Serial Number: WMAZA8235246;
Model: WD10EARX-00PASB0;
Date: 13 APR 2012;
DCM: HHRNNT2MBB;
Product of: Thailand;
PCB Sticker: 2061-771698-T04 AA;
PCB Revision: 2060-771698-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : C9C/3228;
1 : 2 : D31/3377;
2 : 5 : CBE/3262;
3 : 6 : D06/3334;
4 : 7 : CC1/3265;
ROM F/W version……………………. : 0027003R;
Heads map…………………………. : 1,2,5,6,7;
Preamp vendor…………………….. : 0x0000;
Preamp revision…………………… : 0x0005;

;
