HDD with Serial Number: WCC6Y0LZF5VC;
Model: WD1003FZEX-00K3CA0;
Date: 17 SEP 2017;
DCM: HANNKT2AHB;
Product of: Thailand;
PCB Sticker: 800039-401 AB;
PCB Revision: 2060-800039-001 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
ROM F/W version……………………. : 0005005H;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCC6Y5TYDHRF;
Model: WD1003FZEX-00K3CA0;
Date: 27 OCT 2016;
DCM: HANNHT2AHB;
Product of: Thailand;
PCB Sticker: 800039-001 AE;
PCB Revision: 2060-800039-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;

;

ROM F/W version: 0005005H;
Heads map: 0,1;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

HDD with Serial Number: WCC6Y6LPJD10;
Model: WD1003FZEX-00K3CA0;
Date: 07 OCT 2017;
DCM: EANNNT2AHB;
Product of: Thailand;
PCB Sticker: 800039-401 AB;
PCB Revision: 2060-800039-001 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
ROM F/W version……………………. : 0005005H;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCC6Y3YZNK5Y;
Model: WD1003FZEX-00K3CA0;
Date: 15 FEB 2019;
Product of: Thailand;
PCB Sticker: 800039-601 AE;
PCB Revision: 2060-800039-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;

;

ROM F/W: 0005005H;
Heads map: 0,1;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

HDD with Serial Number: WCAW30JYRF89;
Model: WD1003FBYZ-010FB0;
Date: 18 APR 2016;
DCM: HHRNHTJCHB;
Product of: Thailand;
PCB Sticker: 771702-G01 AC;
PCB Revision: 2060-771702-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BB0/2992;
1   : 1   : A8C/2700;
2   : 2   : B54/2900;
3   : 3   : AC8/2760;
ROM F/W version……………………. : 000500AC;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAW37441949;
Model: WD1003FBYZ-010FB0;
Date: 21 FEB 2014;
DCM: HHRNHTJCAB;
Product of: Thailand;
PCB Sticker: 2061-771702-B01 AHD12;
PCB Revision: 2060-771702-001 REV A;
;

ROM F/W version 000500A2;
Heads map:  0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B4C/2892;
1   : 1   : B60/2912;
2   : 2   : B4C/2892;
3   : 3   : B44/2884

;

HDD with Serial Number: WCAW36LLVK68;
Model: WD1003FBYZ-010FB0;
Date: 18 APR 2016;
DCM: HHRNHTJAHB;
Product of: Thailand;
PCB Sticker: 771702-G01 AC;
PCB Revision: 2060-771702-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B0C/2828;
1   : 1   : AF0/2800;
2   : 2   : B2C/2860;
3   : 3   : ABC/2748;
ROM F/W version……………………. : 000500AC;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

HDD with Serial Number: WCAW37523757;
Model: WD1003FBYZ-010FB0;
Date: 09 MAR 2014;
DCM: HHRNHTJAHB;
Product of: Thailand;
PCB Sticker: 2061-771702-B01 AHD12;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A94/2708;
1   : 1   : ADC/2780;
2   : 2   : A68/2664;
3   : 3   : AD8/2776;
ROM F/W version……………………. : 000500A2;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

HDD with Serial Number: WCAW33LHJ5JR;
Model: WD1003FBYZ-010FB0;
Date: 13 MAY 2016;
DCM: HHRNHTJAHB;
Product of: Thailand;
PCB Sticker: 771702-G01 AC;
PCB Revision: 2060-771702-001 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : AE4/2788;
1   : 1   : ACC/2764;
2   : 2   : B3C/2876;
3   : 3   : AF8/2808;
;
ROM F/W Version: 000500AC;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0001

;

HDD with Serial Number: WCAW32FNSDER;
Model: WD1003FBYZ-010FB0;
Date: 04 NOV 2014;
DCM: HHRNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771702-D01 AA;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B30/2864;
1   : 1   : AFC/2812;
2   : 2   : BA8/2984;
3   : 3   : AF4/2804;
ROM F/W version……………………. : 000500AC;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;
;

;

HDD with Serial Number: WCAW37315626;
Model: WD1003FBYZ-010FB0;
Date: 31 JAN 2014;
DCM: HBNNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771702-B01 AHD12;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9E0/2528;
1 : 1 : AF8/2808;
2 : 2 : 9FC/2556;
3 : 3 : AF0/2800;

;

ROM F/W version: 000500A2;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

HDD #1 Specs:;
Serial Number: WCAW37409738;
Model: WD1003FBYZ-010FB0;
Date: 18 SEP 2014 V;
DCM: HARNHTJCH;
Product of: Thailand;
PCB Sticker: 2061-771702-B01 AHD12;
PCB Revision: 2060-771702-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BA0/2976;
1   : 1   : B04/2820;
2   : 2   : BAC/2988;
3   : 3   : B38/2872;
ROM F/W version……………………. : 000500A2;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;
